DAYTON Vertical Band Saw
Model 4TK02A
Operation Manual
Rectangular Cutting Capacity - Horizontal10-3/4 in x 18 in
Throat Depth - Vertical 18 in
Round Cutting Capacity - Horizontal10-3/4 in
SFPM Range 82 to 385
Miter Angle Range 0°
Number of Speed Settings Continuous
Material Application Metal; Wood
Max. Blade Width 5/8 in
Min. Blade Width 1/8 in
Cutting Capacity Square 10.75 in
Blade Thickness 0.035 in
Blade Wheels Dia. 18 in
Max. Blade Length 141 in
Min. Blade Length 138 in
Table Dimensions 21-1/2 in x 23-1/2 in
HP 1.5 hp
Voltage 115/230V
ACPhase1
Amps AC 18.0/9.0 A 60 Hz
Overall Depth 30 in
Overall Height 75 in
Overall Width 37 in
Price: $6,500
Features
Includes Built-In Chip Chute; Cast Iron Pulleys; Chip Blower; Eye
Bolt; Industrial Rated Heavy Duty Speed Reducer; NEMA Frame Motor
with Power Cord; Push Button Magnetic Power Switch; Rip Fence;
Rubberized Cast Iron Wheels; Wheel Cleaning BrushHeavy Gauge Steel
Construction;Cast Iron Wheels; Industrial Rated Heavy Duty Speed
Reducer; Pulleys; Table and LED Blade Speed IndicatorCurrent18.0/9.0
AUNSPSC27112709 Country of OriginTaiwan (subject to change)
